DB243SS

STREET SERIES brake pads are the latest addition to DBA’s comprehensive range of braking products. Aimed at the OE replacement market, the range was developed with three technical objectives in mind – create a brake pad that performs at OE level or better, offers the best friction formulation for the application, and complements DBA’s long-established, market-leading range of STREET SERIES disc rotors.

Great attention was given to the development of the friction formulation to achieve a friction coefficient that outperforms the current market standard. Consequently, DBA did not settle on just one formulation, but offers either ceramic or semi-metallic formulations depending on application and required performance.

DBA recommends STREET SERIES brake pads for everyday use application in passenger cars, SUVs and LightCommercial Vehicles.

DBA recommends use with STREET SERIES plain or T2 slotted disc rotors for increased first application effectiveness and reducing bed-in time.

STREET SERIES part numbers are denoted by the suffix SS.

OE-style post-cured process for optimal braking performance over the pad life

Ceramic* formulation and copper-free (NSFI certified) for low dust emission & clean wheels

High-friction stripe for easy bedding-in

Application-specific NVH shims, slots and chamfers for less vibration and noise

* Check box label for applicability

OE replacement & everyday use

Passenger cars & SUVs

Light commercial Vehicles

Use with DBA Street Series Disc Rotors

Primary FMSI	7111-D145
Set Contains	4 Pads
Width [mm]	89.7
Height [mm]	73.5
Pad Thickness [mm]	16.8
Axle	Front

Compatibility
MERCEDES-BENZ	W123 200	(1979-1985)	1979-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 200 T	Estate (1980-1985)	1980-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 230	(1979-1981)	1979-1981	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 230 C	(1979-1980)	1979-1980	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 230 CE	(1980-1985)	1980-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 230 E	(1980-1985)	1980-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 230 T	Estate (1979-1980)	1979-1980	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 230 TE	Estate (1980-1985)	1980-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 240 D	(1979-1985)	1979-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 240 TD	Estate (1979-1985)	1979-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 250	(1979-1985)	1979-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 250 T	Estate (1979-1982)	1979-1982	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 280	(1979-1981)	1979-1981	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 280 C	(1979-1980)	1979-1980	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 280 CE	(1979-1985)	1979-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 280 E	(1979-1985)	1979-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 280 TE	Estate (1979-1985)	1979-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 300 D	(1979-1985)	1979-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 300 TD	Estate (1979-1985)	1979-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W123 300 TD Turbo	Estate (1980-1985)	1980-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 260 SE	(1985-1991)	1985-1991	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 280 S	(1980-1985)	1980-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 280 SE	(1980-1985)	1980-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 280 SEL	(1980-1985)	1980-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 300 SE	(1985-1991)	1985-1991	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 300 SEL	(1985-1991)	1985-1991	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 380 SE	(1980-1985)	1980-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 380 SEL	(1980-1985)	1980-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 420 SE	(1985-1991)	1985-1991	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 420 SEC	(1985-1991)	1985-1991	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 420 SEL	(1985-1991)	1985-1991	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 500 SE	(1980-1985)	1980-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 500 SE	(1985-1991)	1985-1991	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 500 SEC	(1985-1991)	1985-1991	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 500 SEL	(1980-1985)	1980-1985	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 500 SEL	(1985-1991)	1985-1991	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 560 SE	(1988-1991)	1988-1991	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 560 SEC	(1985-1991)	1985-1991	Front	Brake Caliper: ATE
MERCEDES-BENZ	W126 560 SEL	(1985-1991)	1985-1991	Front	Brake Caliper: ATE
MONTEVERDI	Tiara	3.8 (1982-1984)	1982-1984	Front	Brake Caliper: ATE
MONTEVERDI	Tiara	5.0 (1982-1984)	1982-1984	Front	Brake Caliper: ATE
VOLKSWAGEN	LT	35 (1985-1990)	1985-1990	Front	Brake Caliper: ATE
VOLKSWAGEN	LT	35 (1990-1997)	1990-1997	Front	Brake Caliper: ATE
VOLKSWAGEN	LT	40 (1985-1990)	1985-1990	Front	Brake Caliper: ATE
VOLKSWAGEN	LT	40 (1990-1997)	1990-1997	Front	Brake Caliper: ATE
VOLKSWAGEN	LT	45 (1985-1990)	1985-1990	Front	Brake Caliper: ATE
VOLKSWAGEN	LT	45 (1990-1997)	1990-1997	Front	Brake Caliper: ATE
VOLKSWAGEN	LT	50 (1982-1990)	1982-1990	Front	Brake Caliper: ATE
VOLKSWAGEN	LT	50 (1990-1996)	1990-1996	Front	Brake Caliper: ATE
VOLKSWAGEN	LT	55 (1985-1996)	1985-1996	Front	Brake Caliper: ATE
