DB9022XP

DBA’s Xtreme Performance brake pads have been designed for drivers seeking high initial bite and friction consistency from low to high temperatures. The XP range are for heavy duty applications, where higher friction levels are required, in order to safely brake under extreme conditions.

DBA recommends Xtreme Performance brake pads for street performance and police pursuit vehicles, as well as club track days, heavy towing and upgraded 4WD’s.

DBA recommends T3 slotted rotors in the 4000 & 5000 Series for best stopping performance.

DBA Xtreme Performance part numbers are denoted by the suffix (XP).

• Semi-metallic, carbon fibre friction material
• G-G Class Friction (0.45 average mu from low to high temperatures)
• Excellent high temperature performance
• Optimal braking consistency up to 550℃ (1022℉)

Width [mm]	126.8
Height [mm]	47.9
Pad thickness [mm]	16.6
FMSI	9022-D1793
OEM	FR3Z2200A, FR3Z2200C, FR3Z2200D
Axle	Rear
ECE R90 Number	E11 R90-02A01584/53202

Compatibility
FORD	Mustang (6th Generation)	2.3 Turbo 317BHP Solid Rear Discs (2015-2024)	2015-2024	Rear
FORD	Mustang (6th Generation)	2.3 Turbo 317BHP Vented Rear Discs (2015-2024)	2015-2024	Rear
FORD	Mustang (6th Generation)	5.0 416BHP (2015-2024)	2015-2024	Rear
