DBA
DBA2472S
DBA2472S
Regular price
€202,08 EUR
Regular price
Sale price
€202,08 EUR
Quantity
Couldn't load pickup availability
| Feature Description | Advantage | Benefit |
 "T3 Slot 48 precision CNC machined slots"
|
Tri-Symmetrical curve slots dampens the vibration harmonics or noise | A quieter, responsive and smoother brake pedal feel |
| Increased number of out-gassing exit points for brake pad friction gasses to escape through | Increases the consistency and effectiveness of every brake stop | |
| Universal slot design | Eliminates the need for left and right discs | |
 "KANGAROO_PAW") Kangaroo Paw – 144 diamond and tear drop pillar ventilation system
|
Increased surface area resulting in greater heat dissipation | Minimises brake fade and increases braking effectiveness |
| Increased surface area resulting in greater heat dissipation | Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs | |
 XG150 High Carbon Alloyed Iron
|
An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermal Stability Profiling
|
Special formulation designed to respond to DBA’s TSP process | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermographic Temperature Monitoring
|
Heat paint markings change colour at specific temperature thresholds | Offers the driver a clear indication of peak braking temperatures |
| When temperature thresholds are exceeded paint markings will permanently change colours | Allows the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims | |
 Paint protection on non-friction areas
|
Reduces corrosion | Stops any unsightly rust formation |
| Enhances appearance | Adds value to the product |
| Diameter [mm] | 320 |
| Number of Holes | 5 |
| Inner Diameter [mm] | 69 |
| Thickness [mm] | 28 |
| Height [mm] | 47 |
| Pitch Circle [mm] | 114.3 |
| Stage | Stage 2 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| ECE R90 number | E11*90R02/06*60514*00 |
| Compatibility | |||||
|---|---|---|---|---|---|
| HYUNDAI | i-20 N | 1.6 Turbo 204BHP (2021-) | 2021- | Front | Disc Diameter [mm]: 320 |
| HYUNDAI | i-40 | 1.6 135BHP (2011-2020) | 2011-2020 | Front | Disc Diameter [mm]: 320 |
| HYUNDAI | i-40 | 1.7 TD 115BHP (2011-2020) | 2011-2020 | Front | Disc Diameter [mm]: 320 |
| HYUNDAI | i-40 | 1.7 TD 136BHP (2011-2020) | 2011-2020 | Front | Disc Diameter [mm]: 320 |
| HYUNDAI | i-40 | 2.0 (2011-2020) | 2011-2020 | Front | Disc Diameter [mm]: 320 |
| HYUNDAI | Nexo | Hydrogen (2018-) | 2018- | Front | Disc Diameter [mm]: 320 |
| KIA | Ceed (CD) | 1.6 Turbo 201BHP (2018-) | 2018- | Front | Disc Diameter [mm]: 320 |
| KIA | Cee'd (JD) | 1.6 204BHP (2013-2018) | 2013-2018 | Front | Disc Diameter [mm]: 320 |
| KIA | Cee'd (JD) | 1.6 204BHP Electric Handbrake (2013-2018) | 2013-2018 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima (JF) | 1.6 TD 136BHP (2018-2020) | 2018-2020 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima (JF) | 1.7 TD 139BHP (2016-2018) | 2016-2018 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima (JF) | 2.0 163BHP (2016-2020) | 2016-2020 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima (JF) | 2.0 Turbo 245BHP (2016-2020) | 2016-2020 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima (TF) | 1.7 TD (2012-2016) | 2012-2016 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima (TF) | 1.7 TD Electric Handbrake (2012-2016) | 2012-2016 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima (TF) | 2.0 (2012-2016) | 2012-2016 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima (TF) | 2.0 Electric Handbrake (2012-2016) | 2012-2016 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima (TF) | 2.0 TD (2012-2016) | 2012-2016 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima (TF) | 2.0 TD Electric Handbrake (2012-2016) | 2012-2016 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima (TF) | 2.4 (2012-2016) | 2012-2016 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima (TF) | 2.4 Electric Handbrake (2012-2016) | 2012-2016 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima Sportswagon | 1.6 TD 136BHP (2018-2020) | 2018-2020 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima Sportswagon | 1.7 TD 139BHP (2017-2018) | 2017-2018 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima Sportswagon | 2.0 163BHP (2016-2020) | 2016-2020 | Front | Disc Diameter [mm]: 320 |
| KIA | Optima Sportswagon | 2.0 Turbo 245BHP (2016-2020) | 2016-2020 | Front | Disc Diameter [mm]: 320 |
| KIA | ProCeed (CD) | 1.6 Turbo 201BHP Electric Handbrake (2018-) | 2018- | Front | Disc Diameter [mm]: 320 |
| KIA | Pro-Cee'd (JD) | 1.6 Turbo 204BHP (2013-2018) | 2013-2018 | Front | Disc Diameter [mm]: 320 |
| KIA | Pro-Cee'd (JD) | 1.6 Turbo 204BHP Electric Handbrake (2013-2018) | 2013-2018 | Front | Disc Diameter [mm]: 320 |
| KIA | XCeed | 1.0 Turbo 120BHP Electric Handbrake (2019-) | 2019- | Front | Disc Diameter [mm]: 320 |
| KIA | XCeed | 1.4 Turbo 140BHP Electric Handbrake (2019-) | 2019- | Front | Disc Diameter [mm]: 320 |
| KIA | XCeed | 1.6 PHEV Hybrid 139BHP Electric Handbrake (2020-) | 2020- | Front | Disc Diameter [mm]: 320 |
| KIA | XCeed | 1.6 TD 115BHP Electric Handbrake (2019-) | 2019- | Front | Disc Diameter [mm]: 320 |
| KIA | XCeed | 1.6 TD 136BHP Electric Handbrake (2019-) | 2019- | Front | Disc Diameter [mm]: 320 |
| KIA | XCeed | 1.6 Turbo 204BHP Electric Handbrake (2019-) | 2019- | Front | Disc Diameter [mm]: 320 |
