DBA
DBA2497S
DBA2497S
Regular price
€172,42 EUR
Regular price
Sale price
€172,42 EUR
Quantity
Couldn't load pickup availability
| Feature Description | Advantage | Benefit |
 "T3 Slot 48 precision CNC machined slots"
|
Tri-Symmetrical curve slots dampens the vibration harmonics or noise | A quieter, responsive and smoother brake pedal feel |
| Increased number of out-gassing exit points for brake pad friction gasses to escape through | Increases the consistency and effectiveness of every brake stop | |
| Universal slot design | Eliminates the need for left and right discs | |
 "KANGAROO_PAW") Kangaroo Paw – 144 diamond and tear drop pillar ventilation system
|
Increased surface area resulting in greater heat dissipation | Minimises brake fade and increases braking effectiveness |
| Increased surface area resulting in greater heat dissipation | Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs | |
 XG150 High Carbon Alloyed Iron
|
An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermal Stability Profiling
|
Special formulation designed to respond to DBA’s TSP process | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermographic Temperature Monitoring
|
Heat paint markings change colour at specific temperature thresholds | Offers the driver a clear indication of peak braking temperatures |
| When temperature thresholds are exceeded paint markings will permanently change colours | Allows the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims | |
 Paint protection on non-friction areas
|
Reduces corrosion | Stops any unsightly rust formation |
| Enhances appearance | Adds value to the product |
| Diameter [mm] | 321 |
| Disc Vent | Kangaroo Paw |
| Number of Holes | 5 |
| Inner Diameter [mm] | 70.70 |
| Minimum Thickness [mm] | 27 |
| Thickness [mm] | 30 |
| Height [mm] | 45.60 |
| Stage | Stage 2 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| ECE R90 number | E11*90R02/06*60514*00 |
| Compatibility | |||||||
|---|---|---|---|---|---|---|---|
| OPEL | Astra (J) | 2.0 TD 160BHP (2012-2015) | 2012-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Astra (J) | 2.0 Twin TD 194BHP (2012-2015) | 2012-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Astra GTC (J) | 1.4 100BHP (2011-2014) | 2011-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Astra GTC (J) | 1.4 Turbo 120BHP (2011-2014) | 2011-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Astra GTC (J) | 1.4 Turbo 140BHP (2011-2014) | 2011-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Astra GTC (J) | 1.6 Turbo 170BHP (2012-2013) | 2012-2013 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Astra GTC (J) | 1.6 Turbo 180BHP (2011-2013) | 2011-2013 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Astra GTC (J) | 1.6 Turbo 200BHP (2012-2014) | 2012-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Astra GTC (J) | 1.7 TD 110BHP (2011-2014) | 2011-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Astra GTC (J) | 1.7 TD 130BHP (2011-2014) | 2011-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Astra GTC (J) | 1.8 140BHP (2011-2013) | 2011-2013 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Astra GTC (J) | 2.0 TD 165BHP (2011-2014) | 2011-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Astra GTC (J) | 2.0 Twin TD 194BHP (2012-2014) | 2012-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Cascada | 1.4 Turbo 120BHP (2013-2019) | 2013-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Cascada | 1.4 Turbo 140BHP (2013-2019) | 2013-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Cascada | 1.6 Turbo 170BHP (2013-2019) | 2013-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Cascada | 1.6 Turbo 200BHP (2014-2019) | 2014-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Cascada | 2.0 TD 165BHP (2013-2019) | 2013-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Cascada | 2.0 Twin TD 195BHP (2013-2019) | 2013-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | GTC (J) | 1.4 Turbo 120BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | GTC (J) | 1.4 Turbo 140BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | GTC (J) | 1.6 TD 110BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | GTC (J) | 1.6 TD 136BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | GTC (J) | 1.6 Turbo 200BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | GTC (J) | 2.0 TD 165BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | GTC (J) | 2.0 Twin TD 194BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 1.4 Turbo 120BHP (2011-2019) | 2011-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 1.4 Turbo 140BHP (2011-2019) | 2011-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 1.6 TD 120BHP (2014-2019) | 2014-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 1.6 TD 136BHP (2013-2019) | 2013-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 1.6 Turbo 150BHP (2011-2019) | 2011-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 1.6 Turbo 170BHP (2013-2019) | 2013-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 1.6 Turbo 200BHP (2014-2019) | 2014-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 1.8 115BHP (2011-2019) | 2011-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 1.8 140BHP (2011-2019) | 2011-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 2.0 TD 110BHP (2011-2019) | 2011-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 2.0 TD 130BHP (2011-2019) | 2011-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 2.0 TD 160BHP (2011-2019) | 2011-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| OPEL | Zafira Tourer | 2.0 Twin TD 195BHP (2011-2019) | 2011-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra (J) | 2.0 TD 160BHP (2012-2015) | 2012-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra (J) | 2.0 Twin TD 192BHP (2012-2015) | 2012-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra GTC (J) | 1.4 100BHP (2011-2014) | 2011-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra GTC (J) | 1.4 Turbo 120BHP (2011-2014) | 2011-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra GTC (J) | 1.4 Turbo 140BHP (2011-2014) | 2011-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra GTC (J) | 1.6 Turbo 170BHP (2012-2013) | 2012-2013 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra GTC (J) | 1.6 Turbo 180BHP (2011-2013) | 2011-2013 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra GTC (J) | 1.6 Turbo 200BHP (2012-2014) | 2012-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra GTC (J) | 1.7 TD 110BHP (2011-2014) | 2011-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra GTC (J) | 1.7 TD 130BHP (2011-2014) | 2011-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra GTC (J) | 1.8 140BHP (2011-2013) | 2011-2013 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra GTC (J) | 2.0 TD 165BHP (2011-2014) | 2011-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Astra GTC (J) | 2.0 Twin TD 194BHP (2012-2014) | 2012-2014 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Cascada | 1.4 Turbo 120BHP (2013-2019) | 2013-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Cascada | 1.4 Turbo 140BHP (2013-2019) | 2013-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Cascada | 1.6 Turbo 170BHP (2013-2019) | 2013-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Cascada | 1.6 Turbo 200BHP (2014-2019) | 2014-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Cascada | 2.0 TD 165BHP (2013-2019) | 2013-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Cascada | 2.0 Twin TD 190BHP (2013-2019) | 2013-2019 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | GTC (J) | 1.4 Turbo 120BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | GTC (J) | 1.4 Turbo 140BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | GTC (J) | 1.6 TD 110BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | GTC (J) | 1.6 TD 136BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | GTC (J) | 1.6 Turbo 200BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | GTC (J) | 2.0 TD 165BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | GTC (J) | 2.0 Twin TD 194BHP (2011-2015) | 2011-2015 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Zafira Tourer | 1.4 Turbo 140BHP (2012-2018) | 2012-2018 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Zafira Tourer | 1.6 TD 136BHP (2013-2018) | 2013-2018 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Zafira Tourer | 1.6 Turbo 150BHP (2012-2018) | 2012-2018 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Zafira Tourer | 1.6 Turbo 170BHP (2013-2018) | 2013-2018 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Zafira Tourer | 1.6 Turbo 200BHP (2014-2018) | 2014-2018 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Zafira Tourer | 1.8 115BHP (2012-2018) | 2012-2018 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Zafira Tourer | 1.8 140BHP (2012-2018) | 2012-2018 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Zafira Tourer | 2.0 TD 130BHP (2012-2018) | 2012-2018 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Zafira Tourer | 2.0 TD 160BHP (2012-2018) | 2012-2018 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
| VAUXHALL | Zafira Tourer | 2.0 Twin TD 195BHP (2012-2018) | 2012-2018 | Brake Caliper: Mando | Front | Brake Pads: DB1925 | Disc Diameter [mm]: 321 |
