DBA
DBA2684S
DBA2684S
Regular price
€184,68 EUR
Regular price
Sale price
€184,68 EUR
Quantity
Couldn't load pickup availability
| Feature Description | Advantage | Benefit |
 "T3 Slot 48 precision CNC machined slots"
|
Tri-Symmetrical curve slots dampens the vibration harmonics or noise | A quieter, responsive and smoother brake pedal feel |
| Increased number of out-gassing exit points for brake pad friction gasses to escape through | Increases the consistency and effectiveness of every brake stop | |
| Universal slot design | Eliminates the need for left and right discs | |
 "KANGAROO_PAW") Kangaroo Paw – 144 diamond and tear drop pillar ventilation system
|
Increased surface area resulting in greater heat dissipation | Minimises brake fade and increases braking effectiveness |
| Increased surface area resulting in greater heat dissipation | Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs | |
 XG150 High Carbon Alloyed Iron
|
An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermal Stability Profiling
|
Special formulation designed to respond to DBA’s TSP process | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermographic Temperature Monitoring
|
Heat paint markings change colour at specific temperature thresholds | Offers the driver a clear indication of peak braking temperatures |
| When temperature thresholds are exceeded paint markings will permanently change colours | Allows the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims | |
 Paint protection on non-friction areas
|
Reduces corrosion | Stops any unsightly rust formation |
| Enhances appearance | Adds value to the product |
| Diameter [mm] | 295 |
| Disc Vent | VENTED |
| Number of Holes | 5 |
| Inner Diameter [mm] | 67.00 |
| Minimum Thickness [mm] | 26 |
| Thickness [mm] | 28 |
| Height [mm] | 51.00 |
| Stage | Stage 2 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| ECE R90 number | E11*90R02/06*60536*00 |
| Compatibility | |||||||
|---|---|---|---|---|---|---|---|
| MERCEDES-BENZ | A-Class (W176) A160 | 1.6 Turbo 102BHP (2016-2018) | 2016-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A160 | 1.6 Turbo 102BHP AMG Sport Package (2016-2018) | 2016-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A160D | 1.5TD 90BHP (2013-2018) | 2013-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A160D | 1.5TD 90BHP AMG Sport Package (2013-2018) | 2013-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A180 | 1.6 Turbo 122BHP (2012-2018) | 2012-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A180 | 1.6 Turbo 122BHP AMG Sport Package (2012-2018) | 2012-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A180D | 1.5TD 109BHP (2012-2018) | 2012-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A180D | 1.5TD 109BHP AMG Sport Package (2012-2018) | 2012-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A180D | 1.8TD 109BHP (2012-2018) | 2012-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A180D | 1.8TD 109BHP AMG Sport Package (2012-2018) | 2012-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A200 | 1.6 Turbo 156BHP (2012-2018) | 2012-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A200 | 1.6 Turbo 156BHP AMG Sport Package (2012-2018) | 2012-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A200D | 1.8TD 136BHP (2012-2018) | 2012-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | A-Class (W176) A200D | 1.8TD 136BHP AMG Sport Package (2012-2018) | 2012-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | B-Class (W246) B160D | 1.5TD Sport Package (2013-2018) | 2013-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | B-Class (W246) B180 | 1.6 Turbo (2011-2018) | 2011-2018 | Brake Caliper: TRW | Front | Disc Diameter [mm]: 295 | |
| MERCEDES-BENZ | B-Class (W246) B180 | 1.6 Turbo Sport Package (2011-2018) | 2011-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | B-Class (W246) B180D | 1.5TD Sport Package (2013-2018) | 2013-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | B-Class (W246) B180D | 1.8TD (2011-2018) | 2011-2018 | Brake Caliper: TRW | Front | Disc Diameter [mm]: 295 | |
| MERCEDES-BENZ | B-Class (W246) B180D | 1.8TD Sport Package (2011-2018) | 2011-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | B-Class (W246) B200 | 1.6 Turbo (2011-2018) | 2011-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | B-Class (W246) B200 | 1.6 Turbo Sport Package (2011-2018) | 2011-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | B-Class (W246) B200 | 2.0 Turbo (2012-2018) | 2012-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | B-Class (W246) B200 | 2.0 Turbo Sport Package (2012-2018) | 2012-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | B-Class (W246) B200D | 1.8TD (2011-2018) | 2011-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | B-Class (W246) B200D | 1.8TD Sport Package (2011-2018) | 2011-2018 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA Shooting Brake (X117) CLA180 | 1.6 Turbo 122BHP (2015-2019) | 2015-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA Shooting Brake (X117) CLA180 | 1.6 Turbo 122BHP AMG Sport Package (2015-2019) | 2015-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA Shooting Brake (X117) CLA200 | 1.6 Turbo 156BHP (2015-2019) | 2015-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA Shooting Brake (X117) CLA200 | 1.6 Turbo 156BHP AMG Sport Package (2015-2019) | 2015-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA Shooting Brake (X117) CLA200D | 2.1 TD 136BHP (2015-2019) | 2015-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA Shooting Brake (X117) CLA200D | 2.1 TD 136BHP AMG Sport Package (2015-2019) | 2015-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA Shooting Brake (X117) CLA200D 4Matic | 2.1 TD 136BHP (2015-2019) | 2015-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA Shooting Brake (X117) CLA200D 4Matic | 2.1 TD 136BHP AMG Sport Package (2015-2019) | 2015-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA Shooting Brake (X117) CLA220D | 2.1 TD 177BHP (2015-2019) | 2015-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA Shooting Brake (X117) CLA220D 4Matic | 2.1 TD 177BHP (2015-2019) | 2015-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA-Class (C117) CLA180 | 1.6 Turbo 122BHP (2013-2019) | 2013-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA-Class (C117) CLA180 | 1.6 Turbo 122BHP AMG Sport Package (2013-2019) | 2013-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA-Class (C117) CLA200 | 1.6 Turbo 156BHP (2013-2019) | 2013-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA-Class (C117) CLA200 | 1.6 Turbo 156BHP AMG Sport Package (2013-2019) | 2013-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA-Class (C117) CLA200D | 1.8 TD 136BHP (2013-2014) | 2013-2014 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA-Class (C117) CLA200D | 2.1 TD 136BHP (2014-2019) | 2014-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA-Class (C117) CLA200D | 2.1 TD 136BHP AMG Sport Package (2014-2019) | 2014-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA-Class (C117) CLA200D 4Matic | 2.1 TD 136BHP (2014-2019) | 2014-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA-Class (C117) CLA200D 4Matic | 2.1 TD 136BHP AMG Sport Package (2014-2019) | 2014-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA-Class (C117) CLA220D | 2.1 TD 170BHP (2013-2014) | 2013-2014 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA-Class (C117) CLA220D | 2.1 TD 177BHP (2014-2019) | 2014-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | CLA-Class (C117) CLA220D 4Matic | 2.1 TD 177BHP (2014-2019) | 2014-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | GLA-Class (X156) GLA180 | 1.5 TD 109BHP (2014-2019) | 2014-2019 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | GLA-Class (X156) GLA180 | 1.6 122BHP (2014-2020) | 2014-2020 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | GLA-Class (X156) GLA180 | 1.6 122BHP AMG Line (2014-2020) | 2014-2020 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | GLA-Class (X156) GLA200 | 1.6 156BHP (2014-2020) | 2014-2020 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | GLA-Class (X156) GLA200 | 1.6 156BHP AMG Line (2014-2020) | 2014-2020 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | GLA-Class (X156) GLA200 | 2.1TD 136BHP (2014-2020) | 2014-2020 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | GLA-Class (X156) GLA200 | 2.1TD 136BHP AMG Line (2014-2020) | 2014-2020 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | GLA-Class (X156) GLA200 4Matic | 2.1TD 136BHP (2014-2020) | 2014-2020 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | GLA-Class (X156) GLA220 | 2.1TD 168BHP (2014-2020) | 2014-2020 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | GLA-Class (X156) GLA220 4Matic | 2.1TD 168BHP (2014-2020) | 2014-2020 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | GLA-Class (X156) GLA250 | 2.0 Turbo 208BHP (2014-2020) | 2014-2020 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
| MERCEDES-BENZ | GLA-Class (X156) GLA250 4Matic | 2.0 Turbo 208BHP (2014-2020) | 2014-2020 | Brake Caliper: TRW | Front | Brake Pads: DB2315 | Disc Diameter [mm]: 295 |
