DBA
DBA42163S
DBA42163S
Regular price
€292,18 EUR
Regular price
Sale price
€292,18 EUR
Quantity
Couldn't load pickup availability
| Feature Description | Advantage | Benefit |
 "T3 Slot 48 precision CNC machined slots"
|
Tri-Symmetrical curve slots dampens the vibration harmonics or noise | A quieter, responsive and smoother brake pedal feel |
| Increased number of out-gassing exit points for brake pad friction gasses to escape through | Increases the consistency and effectiveness of every brake stop | |
| Universal slot design | Eliminates the need for left and right discs | |
 "KANGAROO_PAW") Kangaroo Paw – 144 diamond and tear drop pillar ventilation system
|
Increased surface area resulting in greater heat dissipation | Minimises brake fade and increases braking effectiveness |
| Increased surface area resulting in greater heat dissipation | Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs | |
 XG150 High Carbon Alloyed Iron
|
An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermal Stability Profiling
|
Special formulation designed to respond to DBA’s TSP process | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermographic Temperature Monitoring
|
Heat paint markings change colour at specific temperature thresholds | Offers the driver a clear indication of peak braking temperatures |
| When temperature thresholds are exceeded paint markings will permanently change colours | Allows the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims | |
 Paint protection on non-friction areas
|
Reduces corrosion | Stops any unsightly rust formation |
| Enhances appearance | Adds value to the product |
| Diameter [mm] | 278 |
| Disc Vent | Kangaroo Paw |
| Number of Holes | 4 |
| Minimum Thickness [mm] | 21 |
| Thickness [mm] | 23 |
| Height [mm] | 44 |
| Hole diameter[mm] | 63,5 |
| Stage | Stage 4 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| ECE R90 number | E11 90R-02C01704/72743 |
| Compatibility | |||||||
|---|---|---|---|---|---|---|---|
| FORD | B-Max | 1.0 Turbo 100BHP (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | B-Max | 1.0 Turbo 100BHP Pad with wear clip (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Disc Diameter [mm]: 278 | |
| FORD | B-Max | 1.0 Turbo 120BHP (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | B-Max | 1.0 Turbo 120BHP Pad with wear clip (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Disc Diameter [mm]: 278 | |
| FORD | B-Max | 1.0 Turbo 140BHP (2016-2017) | 2016-2017 | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | B-Max | 1.0 Turbo 140BHP Pad with wear clip (2016-2017) | 2016-2017 | Brake Caliper: TRW | Front | Disc Diameter [mm]: 278 | |
| FORD | B-Max | 1.4 90BHP (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | B-Max | 1.4 90BHP Pad with wear clip (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Disc Diameter [mm]: 278 | |
| FORD | B-Max | 1.5 TD 75BHP (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | B-Max | 1.5 TD 75BHP Pad with wear clip (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Disc Diameter [mm]: 278 | |
| FORD | B-Max | 1.5 TD 95BHP (2015-2017) | 2015-2017 | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | B-Max | 1.5 TD 95BHP Pad with wear clip (2015-2017) | 2015-2017 | Brake Caliper: TRW | Front | Disc Diameter [mm]: 278 | |
| FORD | B-Max | 1.6 105BHP (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | B-Max | 1.6 105BHP Pad with wear clip (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Disc Diameter [mm]: 278 | |
| FORD | B-Max | 1.6 TD 95BHP (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | B-Max | 1.6 TD 95BHP Pad with wear clip (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Disc Diameter [mm]: 278 | |
| FORD | Fiesta (Mk7) | 1.6 Turbo ST 182BHP (2012-2017) | 2012-2017 | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | Fiesta (Mk7) | 1.6 Turbo ST 200BHP (2016-2017) | 2016-2017 | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | Fiesta (Mk8) | 1.5 Turbo ST 200BHP (2018-) | 2018- | Brake Caliper: ATE | Front | Brake Pads: DB15149 | Disc Diameter [mm]: 278 |
| FORD | Tourneo Courier | 1.0 Turbo 100BHP (2014-) | 2014- | Brake Caliper: ATE | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | Tourneo Courier | 1.5 TD 75BHP (2014-) | 2014- | Brake Caliper: ATE | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | Tourneo Courier | 1.5 TD 95BHP (2015-) | 2015- | Brake Caliper: ATE | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | Tourneo Courier | 1.6 TD 95BHP (2014-) | 2014- | Brake Caliper: ATE | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | Transit Courier | 1.0 Turbo 100BHP (2014-) | 2014- | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | Transit Courier | 1.5 TD 75BHP (2014-) | 2014- | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | Transit Courier | 1.5 TD 95BHP (2015-) | 2015- | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
| FORD | Transit Courier | 1.6 TD 95BHP (2014-) | 2014- | Brake Caliper: TRW | Front | Brake Pads: DB2382 | Disc Diameter [mm]: 278 |
