TS-0622-6212

Ford Powerstroke 7.3L Internal Wastegate Actuator (IWG) provides better turbo response and greater sensitivity when managing boost pressures. Designed as a direct bolt-on replacement for the factory part, the IWG is easy to install and requires no special tools or fabrication. We've taken the proven technology from our WG38, 40 and 45mm External Wastegates and applied it to the Internal Wastegate Actuator.

FEATURES:
• Silicone diaphragm with Nomex reinforcement to withstand high temperatures.
• High grade, billet aluminum construction.
• Stainless steel rods and connecting clevis for corrosion resistance.
• Locking Collar design cap allows for quick spring changes.
• Ideal for use with any Turbosmart boost controller.

Supplied With:
Fitting Hardware, Adjustment Nuts, Brown/Red 11psi Middle Spring and Brown/Blue 10psi Outer Spring (installed).

Tech Bulletins

TS-06XX-XXXX IWG75 Clevis Type Instructions.pdf

Compatibility
FORD	F-350	9th Generation (01/94-06/05) 205KW 275HP 7298cc DIESEL TRUCK (7.3L Powerstroke)
FORD	SUPER DUTY	(01/99-12/03) 205KW 275HP 7298cc DIESEL TRUCK (7.3L Powerstroke)
FORD	EXCURSION	(01/00-12/03) 205KW 275HP 7298cc DIESEL TRUCK (7.3L Powerstroke)
FORD	E-SERIES	(01/94-12/03) 205KW 275HP 7298cc DIESEL TRUCK (7.3L Powerstroke)
