CT-1 is a Dry Film Lubricant coating that helps reduce friction and abrasive wear. It provides intermittent dry lubrication and is not affected by dust or dirt. CT-1 is specifically engineered to withstand the extreme conditions of today’s high performance engines. Professional engine builders enjoy a higher level of confidence with increased embedability, strength and durability.
PROCESS
CT-1 Dry Film Lubricant coating is applied as a spray process. Different surface preparation methods appropriate for the substrates will be used prior to the coating process.
Coating thickness is varied to suit the application. Typical coating thickness for engine bearings is 0.00025” to 0.00030” inch (6 to 7.5 microns)
ADVANTAGES
Provides intermittent dry lubrication, not affected by dust or dirt, low coefficient of friction. Thin coating to accommodate assembly constraints, chemical resistance, corrosion protection, reduced friction and drag resulting in decreased parasitic losses.
- Corrosion Protection
- Increased Lubricity
- Low Coefficient of Friction
- Oil and Fuel Resistant
EMBEDABILITY
CT-1 coated bearings have excellent embedability characteristics, allowing debris contaminates to embed in the bearing, avoiding damage to the crank
EXTREME OIL TEMPERATURES
CT-1 coated bearings have shown a reduction in oil temperatures as much as 8°C - 11°C / 15˚F - 20˚F. Lower oil temperatures also aid in the loss of viscosity due to extreme heat.
LOW OIL PRESSURE/OIL STARVATION
Theoretically a crankshaft rides on a thin film of oil that protects both the crank and bearing. Real world experience such as cold starts and rough terrain conditions have proven otherwise. CT-1 coated engine bearings provide a dry film lubricant that protects against intermediate oil starvation
| Tunnel [mm] | 62.000/62.013 |
| Shaft [mm] | 57.982/57.995 |
| Max. Wall | 1.992 (+0.25) |
| Max. Length | 19.5 |
| Half type | Identical halves |
| Note | Overwidth flanges for undersizes: Std=Std, .25mm=Std+.20mm, .50mm=Std+.40mm |
| Compatibility | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Daewoo | All | SOHC | C20LE | 4 | 5M2327HC | 1998 cc | DOHC v16 | -.50 | 86.0 | 86.0 |
| Daewoo | All | DOHC | C20SED | 4 | 5M2327HC | 1998 cc | SOHC/OHC v16 | -.50 | 86.0 | 86.0 |
| GM | All | SOHC | 110ci | 5M2327HC | -.50 | |||||
| GM | All | SOHC | 110ci Turbo | 5M2327HC | -.50 | |||||
| GM | All | SOHC | 122ci | 5M2327HC | -.50 | |||||
| GM | All | SOHC | 122ci Turbo | 5M2327HC | -.50 | |||||
| Holden | All | SOHC | 16JH | 4 | 5M2327HC | 1598 cc | SOHC/OHC v8 | -.50 | 80.0 | 79.5 |
| Holden | All | SOHC | 16LF | 4 | 5M2327HC | 1598 cc | SOHC/OHC v8 | -.50 | 80.0 | 79.5 |
| Holden | All | SOHC | 18JC | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Holden | All | SOHC | 18JU | 5M2327HC | -.50 | |||||
| Holden | All | SOHC | 18LE | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Holden | All | SOHC | 20JD | 5M2327HC | -.50 | |||||
| Holden | All | DOHC | C18SEL | 4 | 5M2327HC | 1799 cc | DOHC v16 | -.50 | 81.6 | 86.0 |
| Holden | All | DOHC | C18XE | 4 | 5M2327HC | 1799 cc | DOHC v16 | -.50 | 81.6 | 86.0 |
| Holden | All | DOHC | C20LET | 4 | 5M2327HC | 1998 cc | DOHC v16 | -.50 | 86.0 | 86.0 |
| Holden | All | SOHC | C20NE | 4 | 5M2327HC | 1998 cc | SOHC/OHC v8 | -.50 | 86.0 | 86.0 |
| Holden | All | DOHC | C20SEL | 4 | 5M2327HC | 1998 cc | DOHC v16 | -.50 | 86.0 | 86.0 |
| Holden | All | DOHC | C20XE | 4 | 5M2327HC | 1998 cc | DOHC v16 | -.50 | 86.0 | 86.0 |
| Holden | All | DOHC | X18XE | 4 | 5M2327HC | 1799 cc | DOHC v16 | -.50 | 81.6 | 86.0 |
| Holden | All | SOHC | X20SE | 4 | 5M2327HC | 1998 cc | SOHC/OHC v8 | -.50 | 86.0 | 86.0 |
| Holden | All | DOHC | X20XEV | 4 | 5M2327HC | 1998 cc | DOHC v16 | -.50 | 86.0 | 86.0 |
| Holden | All | DOHC | Z18XE | 4 | 5M2327HC | 1796 cc | DOHC v16 | -.50 | 80.5 | 88.2 |
| Holden | All | DOHC | Z20LET | 4 | 5M2327HC | 1998 cc | DOHC v16 | -.50 | 86.0 | 86.0 |
| Opel | All | SOHC | 16D | 4 | 5M2327HC | 1598 cc | SOHC/OHC v8 | -.50 | 80.0 | 79.5 |
| Opel | All | SOHC | 16DA | 4 | 5M2327HC | 1598 cc | SOHC/OHC v8 | -.50 | 80.0 | 79.5 |
| Opel | All | SOHC | 16N | 4 | 5M2327HC | 1598 cc | CIH v8 | -.50 | 79.0 | 81.5 |
| Opel | All | SOHC | 16SH | 4 | 5M2327HC | 1598 cc | SOHC/OHC v8 | -.50 | 79.0 | 81.5 |
| Opel | All | SOHC | 17D | 4 | 5M2327HC | 1699 cc | SOHC/OHC v8 | -.50 | 82.5 | 79.5 |
| Opel | All | SOHC | 17DR | 4 | 5M2327HC | 1699 cc | SOHC/OHC v8 | -.50 | 82.5 | 79.5 |
| Opel | All | SOHC | 18E | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Opel | All | SOHC | 18S | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Opel | All | SOHC | 18SV | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Opel | All | SOHC | 20NE | 4 | 5M2327HC | 1998 cc | SOHC/OHC v8 | -.50 | 86.0 | 86.0 |
| Opel | All | SOHC | 20NEJ | 4 | 5M2327HC | 1998 cc | SOHC/OHC v8 | -.50 | 86.0 | 86.0 |
| Opel | All | SOHC | 20SER | 4 | 5M2327HC | 1998 cc | SOHC/OHC v8 | -.50 | 86.0 | 86.0 |
| Opel | All | DOHC | 20XE | 4 | 5M2327HC | 1998 cc | DOHC v16 | -.50 | 86.0 | 86.0 |
| Opel | All | SOHC | C18NE | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Opel | All | SOHC | C18NT | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Opel | All | SOHC | C18NV | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Opel | All | SOHC | C18NZ | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Opel | All | SOHC | S18NV | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Opel | All | DOHC | Y22SE | 4 | 5M2327HC | 2198 cc | DOHC v16 | -.50 | 86.0 | 94.6 |
| Opel | All | SOHC | 18N | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Opel | All | SOHC | NV | 4 | 5M2327HC | 1196 cc | SOHC/OHC v8 | -.50 | 77.8 | 62.9 |
| Opel | All | SOHC | 18SE | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Opel | All | SOHC | 18SEH | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Opel | All | SOHC | 20SE | 4 | 5M2327HC | 1998 cc | SOHC/OHC v8 | -.50 | 86.0 | 86.0 |
| Opel | All | SOHC | 20SEH | 4 | 5M2327HC | 1998 cc | SOHC/OHC v8 | -.50 | 86.0 | 86.0 |
| Opel | All | DOHC | C18XE | 4 | 5M2327HC | 1799 cc | DOHC v16 | -.50 | 81.6 | 86.0 |
| Opel | All | DOHC | C18XEL | 4 | 5M2327HC | 1799 cc | DOHC v16 | -.50 | 81.6 | 86.0 |
| Opel | All | SOHC | C20NE | 4 | 5M2327HC | 1998 cc | SOHC/OHC v8 | -.50 | 86.0 | 86.0 |
| Opel | All | SOHC | C20NEF | 4 | 5M2327HC | 1998 cc | SOHC/OHC v8 | -.50 | 86.0 | 86.0 |
| Opel | All | SOHC | E18NV | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
| Opel | All | SOHC | E18NVR | 4 | 5M2327HC | 1796 cc | SOHC/OHC v8 | -.50 | 84.8 | 79.5 |
