DBA
DBA2174S
DBA2174S
Prezzo di listino
€241,48 EUR
Prezzo di listino
Prezzo scontato
€241,48 EUR
Quantità
Impossibile caricare la disponibilità di ritiro
| Feature Description | Advantage | Benefit |
 "T3 Slot 48 precision CNC machined slots"
|
Tri-Symmetrical curve slots dampens the vibration harmonics or noise | A quieter, responsive and smoother brake pedal feel |
| Increased number of out-gassing exit points for brake pad friction gasses to escape through | Increases the consistency and effectiveness of every brake stop | |
| Universal slot design | Eliminates the need for left and right discs | |
 "KANGAROO_PAW") Kangaroo Paw – 144 diamond and tear drop pillar ventilation system
|
Increased surface area resulting in greater heat dissipation | Minimises brake fade and increases braking effectiveness |
| Increased surface area resulting in greater heat dissipation | Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs | |
 XG150 High Carbon Alloyed Iron
|
An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermal Stability Profiling
|
Special formulation designed to respond to DBA’s TSP process | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermographic Temperature Monitoring
|
Heat paint markings change colour at specific temperature thresholds | Offers the driver a clear indication of peak braking temperatures |
| When temperature thresholds are exceeded paint markings will permanently change colours | Allows the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims | |
 Paint protection on non-friction areas
|
Reduces corrosion | Stops any unsightly rust formation |
| Enhances appearance | Adds value to the product |
| Diameter [mm] | 326 |
| Number of Holes | 5 |
| Inner Diameter [mm] | 71 |
| Thickness [mm] | 30 |
| Height [mm] | 46.2 |
| Pitch Circle [mm] | 0 |
| Stage | Stage 2 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| ECE R90 number | E11*90R02/06*60533*00 |
| Compatibility | ||||||
|---|---|---|---|---|---|---|
| JAGUAR | S-Type | 2.7 TD 204BHP (2006-2008) | 2006-2008 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | S-Type | 3.0 235BHP (2006-2008) | 2006-2008 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | S-Type | 4.2 294BHP (2006-2008) | 2006-2008 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XF (X250) | 2.0 Turbo 241BHP (2012-2015) | 2012-2015 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XF (X250) | 2.2 TD 163BHP (2011-2015) | 2011-2015 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XF (X250) | 2.2 TD 190BHP (2011-2012) | 2011-2012 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XF (X250) | 2.2 TD 200BHP (2012-2015) | 2012-2015 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XF (X250) | 2.7 Twin TD 207BHP (2008-2009) | 2008-2009 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XF (X250) | 3.0 238BHP (2008-2012) | 2008-2012 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XF (X250) | 3.0 Twin TD 211BHP (2009-2011) | 2009-2011 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XF (X250) | 3.0 Twin TD 240BHP (2009-2015) | 2009-2015 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XF (X250) | 4.2 300BHP (2008-2009) | 2008-2009 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XF Sportbrake | 2.2 TD 163BHP (2012-2016) | 2012-2016 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XF Sportbrake | 2.2 TD 200BHP (2012-2016) | 2012-2016 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XF Sportbrake | 3.0 Twin TD 240BHP (2012-2016) | 2012-2016 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XJ6 | 2.7 TD (2006-2009) | 2006-2009 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XJ6 | 3.0 (2006-2009) | 2006-2009 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XJ8 | 3.5 (2006-2009) | 2006-2009 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XJ8 | 4.2 (2006-2009) | 2006-2009 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XK | 3.5 (2007-2009) | 2007-2009 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
| JAGUAR | XK | 4.2 (2006-2014) | 2006-2014 | Brake Caliper: ATE | Front | Disc Diameter [mm]: 326 |
