DBA
DBA2376S
DBA2376S
Prezzo di listino
€241,48 EUR
Prezzo di listino
Prezzo scontato
€241,48 EUR
Quantità
Impossibile caricare la disponibilità di ritiro
| Feature Description | Advantage | Benefit |
 "T3 Slot 48 precision CNC machined slots"
|
Tri-Symmetrical curve slots dampens the vibration harmonics or noise | A quieter, responsive and smoother brake pedal feel |
| Increased number of out-gassing exit points for brake pad friction gasses to escape through | Increases the consistency and effectiveness of every brake stop | |
| Universal slot design | Eliminates the need for left and right discs | |
 "KANGAROO_PAW") Kangaroo Paw – 144 diamond and tear drop pillar ventilation system
|
Increased surface area resulting in greater heat dissipation | Minimises brake fade and increases braking effectiveness |
| Increased surface area resulting in greater heat dissipation | Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs | |
 XG150 High Carbon Alloyed Iron
|
An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermal Stability Profiling
|
Special formulation designed to respond to DBA’s TSP process | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermographic Temperature Monitoring
|
Heat paint markings change colour at specific temperature thresholds | Offers the driver a clear indication of peak braking temperatures |
| When temperature thresholds are exceeded paint markings will permanently change colours | Allows the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims | |
 Paint protection on non-friction areas
|
Reduces corrosion | Stops any unsightly rust formation |
| Enhances appearance | Adds value to the product |
| Diameter [mm] | 336 |
| Disc Vent | Vented |
| Number of Holes | 5 |
| Inner Diameter [mm] | 68 |
| Minimum Thickness [mm] | 27 |
| Thickness [mm] | 30 |
| Height [mm] | 50.4 |
| Pitch Circle [mm] | 108 |
| Stage | Stage 2 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| ECE R90 number | E11*90R02/06*60532*00 |
| Compatibility | |||||||
|---|---|---|---|---|---|---|---|
| VOLVO | XC90 (1st Gen) | 2.4 TD 163BHP (2002-2006) | 2002-2006 | Brake Caliper: ATE | Front | Brake Pads: DB1661 | Disc Diameter [mm]: 336 |
| VOLVO | XC90 (1st Gen) | 2.4 TD 163BHP (2006-2015) | 2006-2015 | Brake Caliper: ATE | Front | Brake Pads: DB1661 | Disc Diameter [mm]: 336 |
| VOLVO | XC90 (1st Gen) | 2.4 TD 185BHP (2006-2015) | 2006-2015 | Brake Caliper: ATE | Front | Brake Pads: DB1661 | Disc Diameter [mm]: 336 |
| VOLVO | XC90 (1st Gen) | 2.4 TD 200BHP (2011-2015) | 2011-2015 | Brake Caliper: ATE | Front | Brake Pads: DB1661 | Disc Diameter [mm]: 336 |
| VOLVO | XC90 (1st Gen) | 2.5 Turbo 208BHP (2002-2006) | 2002-2006 | Brake Caliper: ATE | Front | Brake Pads: DB1661 | Disc Diameter [mm]: 336 |
| VOLVO | XC90 (1st Gen) | 3.2 238BHP (2006-2010) | 2006-2010 | Brake Caliper: ATE | Front | Brake Pads: DB1661 | Disc Diameter [mm]: 336 |
| VOLVO | XC90 (1st Gen) | 3.2 243BHP (2010-2015) | 2010-2015 | Brake Caliper: ATE | Front | Brake Pads: DB1661 | Disc Diameter [mm]: 336 |
| VOLVO | XC90 (1st Gen) | 4.4 315BHP (2006-2012) | 2006-2012 | Brake Caliper: ATE | Front | Brake Pads: DB1661 | Disc Diameter [mm]: 336 |
| VOLVO | XC90 (1st Gen) t6 | 2.9 272BHP (2002-2006) | 2002-2006 | Brake Caliper: ATE | Front | Brake Pads: DB1661 | Disc Diameter [mm]: 336 |
