DBA
DBA2383S
DBA2383S
Prezzo di listino
€187,25 EUR
Prezzo di listino
Prezzo scontato
€187,25 EUR
Quantità
Impossibile caricare la disponibilità di ritiro
| Feature Description | Advantage | Benefit |
 "T3 Slot 48 precision CNC machined slots"
|
Tri-Symmetrical curve slots dampens the vibration harmonics or noise | A quieter, responsive and smoother brake pedal feel |
| Increased number of out-gassing exit points for brake pad friction gasses to escape through | Increases the consistency and effectiveness of every brake stop | |
| Universal slot design | Eliminates the need for left and right discs | |
 "KANGAROO_PAW") Kangaroo Paw – 144 diamond and tear drop pillar ventilation system
|
Increased surface area resulting in greater heat dissipation | Minimises brake fade and increases braking effectiveness |
| Increased surface area resulting in greater heat dissipation | Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs | |
 XG150 High Carbon Alloyed Iron
|
An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermal Stability Profiling
|
Special formulation designed to respond to DBA’s TSP process | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermographic Temperature Monitoring
|
Heat paint markings change colour at specific temperature thresholds | Offers the driver a clear indication of peak braking temperatures |
| When temperature thresholds are exceeded paint markings will permanently change colours | Allows the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims | |
 Paint protection on non-friction areas
|
Reduces corrosion | Stops any unsightly rust formation |
| Enhances appearance | Adds value to the product |
| Diameter [mm] | 288 |
| Disc Vent | Solid |
| Number of Holes | 5 |
| Inner Diameter [mm] | 68 |
| Minimum Thickness [mm] | 10 |
| Thickness [mm] | 12 |
| Height [mm] | 65 |
| Stage | Stage 2 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| Compatibility | |||||||
|---|---|---|---|---|---|---|---|
| VOLVO | Cross Country | 2.4 Turbo (2001-2002) | 2001-2002 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S60 (Mk1) | 2.0 Turbo (2000-2010) | 2000-2010 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S60 (Mk1) | 2.3 Turbo (2000-2010) | 2000-2010 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S60 (Mk1) | 2.4 (2000-2010) | 2000-2010 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S60 (Mk1) | 2.4 TD (2001-2010) | 2001-2010 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S60 (Mk1) | 2.4 Turbo (2000-2004) | 2000-2004 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S60 (Mk1) | 2.5 Turbo (2003-2009) | 2003-2009 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S60 (Mk1) T5 | 2.3 Turbo (2000-2004) | 2000-2004 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S60 (Mk1) T5 | 2.4 Turbo (2005-2007) | 2005-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S70 | 2.3 Turbo R 2WD (1999-2000) | 1999-2000 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 288 | |
| VOLVO | S80 (Mk1) | 2.0 Turbo 177BHP (2003-2006) | 2003-2006 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S80 (Mk1) | 2.4 (1998-2006) | 1998-2006 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S80 (Mk1) | 2.4 TD (2001-2006) | 2001-2006 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S80 (Mk1) | 2.4 Turbo 197BHP (2002-2003) | 2002-2003 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S80 (Mk1) | 2.5 TD (1998-2006) | 1998-2006 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S80 (Mk1) | 2.5 Turbo 211BHP (2002-2006) | 2002-2006 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S80 (Mk1) | 2.9 204BHP (1998-2006) | 1998-2006 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | S80 (Mk1) T6 | 2.9 Turbo 270BHP (1998-2006) | 1998-2006 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | V70 (Mk1) | 2.3 Turbo R 2WD (1997-1999) | 1997-1999 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 288 | |
| VOLVO | V70 (Mk2) | 2.0 Turbo (2003-2007) | 2003-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | V70 (Mk2) | 2.3 Turbo R 2WD (2000-2002) | 2000-2002 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | V70 (Mk2) | 2.4 (2000-2007) | 2000-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | V70 (Mk2) | 2.4 (2004-2007) | 2004-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | V70 (Mk2) | 2.4 TD (2000-2007) | 2000-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | V70 (Mk2) | 2.4 TD (2004-2007) | 2004-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | V70 (Mk2) | 2.4 Turbo (2000-2007) | 2000-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | V70 (Mk2) | 2.5 Turbo (2001-2007) | 2001-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | V70 (Mk2) T5 | 2.3 Turbo (2000-2007) | 2000-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | V70 (Mk2) T5 | 2.3 Turbo (2004-2007) | 2004-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | V70 (Mk2) T5 | 2.4 Turbo (2004-2007) | 2004-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | V70 XC | 2.4 Turbo (2000-2002) | 2000-2002 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | XC70 (Mk1) | 2.4 TD (2002-2007) | 2002-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | XC70 (Mk1) | 2.4 Turbo (2002-2003) | 2002-2003 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
| VOLVO | XC70 (Mk1) | 2.5 Turbo (2002-2007) | 2002-2007 | Brake Caliper: ATE | Rear | Brake Pads: DB1456 | Disc Diameter [mm]: 288 |
