DBA
DBA2824S
DBA2824S
Prezzo di listino
€214,36 EUR
Prezzo di listino
Prezzo scontato
€214,36 EUR
Quantità
Impossibile caricare la disponibilità di ritiro
| Feature Description | Advantage | Benefit |
 "T3 Slot 48 precision CNC machined slots"
|
Tri-Symmetrical curve slots dampens the vibration harmonics or noise | A quieter, responsive and smoother brake pedal feel |
| Increased number of out-gassing exit points for brake pad friction gasses to escape through | Increases the consistency and effectiveness of every brake stop | |
| Universal slot design | Eliminates the need for left and right discs | |
 "KANGAROO_PAW") Kangaroo Paw – 144 diamond and tear drop pillar ventilation system
|
Increased surface area resulting in greater heat dissipation | Minimises brake fade and increases braking effectiveness |
| Increased surface area resulting in greater heat dissipation | Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs | |
 XG150 High Carbon Alloyed Iron
|
An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermal Stability Profiling
|
Special formulation designed to respond to DBA’s TSP process | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermographic Temperature Monitoring
|
Heat paint markings change colour at specific temperature thresholds | Offers the driver a clear indication of peak braking temperatures |
| When temperature thresholds are exceeded paint markings will permanently change colours | Allows the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims | |
 Paint protection on non-friction areas
|
Reduces corrosion | Stops any unsightly rust formation |
| Enhances appearance | Adds value to the product |
| Diameter [mm] | 314 |
| Disc Vent | Vented |
| Number of Holes | 5 |
| Inner Diameter [mm] | 68 |
| Minimum Thickness [mm] | 28 |
| Thickness [mm] | 30 |
| Height [mm] | 52 |
| Stage | Stage 2 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| ECE R90 number | E11*90R02/06*60521*00 |
| Compatibility | |||||||
|---|---|---|---|---|---|---|---|
| AUDI | A4 Allroad quattro | 2.0 TD (2009-2016) | 2009-2016 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 Allroad quattro | 2.0 Turbo (2009-2016) | 2009-2016 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 Allroad quattro Mk2 | 2.0 TD 163BHP (2016-) | 2016- | Brake Caliper: ATE | Front | Disc Diameter [mm]: 314 | |
| AUDI | A4 B8 | 1.8 Turbo 120BHP (2008-2011) | 2008-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 B8 | 1.8 Turbo 160BHP (2008-2011) | 2008-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 B8 | 1.8 Turbo 170BHP (2011-2015) | 2011-2015 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 B8 | 2.0 TD (2008-2011) | 2008-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 B8 | 2.0 TD (2011-2015) | 2011-2015 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 B8 | 2.0 Turbo 180BHP (2008-2011) | 2008-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 B8 | 2.0 Turbo 180BHP (2011-2015) | 2011-2015 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 B8 | 2.0 Turbo 211BHP (2008-2011) | 2008-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 B8 | 2.0 Turbo 211BHP (2011-2015) | 2011-2015 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 B8 | 2.0 Turbo 220BHP (2013-2015) | 2013-2015 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 B9 | 1.4 Turbo 150BHP (2015-) | 2015- | Brake Caliper: ATE | Front | Disc Diameter [mm]: 314 | |
| AUDI | A4 B9 | 2.0 TD 150BHP (2015-) | 2015- | Brake Caliper: ATE | Front | Disc Diameter [mm]: 314 | |
| AUDI | A4 B9 | 2.0 Turbo 190BHP (2015-) | 2015- | Brake Caliper: ATE | Front | Disc Diameter [mm]: 314 | |
| AUDI | A4 quattro B8 | 1.8 Turbo (2008-2015) | 2008-2015 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 quattro B8 | 2.0 TD (2011-2015) | 2011-2015 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 quattro B8 | 2.0 TD 143BHP (2008-2011) | 2008-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 quattro B8 | 2.0 TD 170BHP (2008-2011) | 2008-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A4 quattro B8 | 2.0 Turbo (2008-2011) | 2008-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 B8 | 1.8 Turbo 158BHP (2009-2017) | 2009-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 B8 | 1.8 Turbo 168BHP (2007-2017) | 2007-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 B8 | 2.0 TD 134BHP (2011-2017) | 2011-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 B8 | 2.0 TD 141BHP (2009-2017) | 2009-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 B8 | 2.0 TD 168BHP (2008-2011) | 2008-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 B8 | 2.0 TD 174BHP (2011-2017) | 2011-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 B8 | 2.0 Turbo 177BHP (2008-2011) | 2008-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 B8 | 2.0 Turbo 208BHP (2011-2017) | 2011-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 B9 | 2.0 TD 150BHP (2016-) | 2016- | Brake Caliper: ATE | Front | Disc Diameter [mm]: 314 | |
| AUDI | A5 B9 | 2.0 TD 190BHP (2016-) | 2016- | Brake Caliper: ATE | Front | Disc Diameter [mm]: 314 | |
| AUDI | A5 B9 | 2.0 Turbo 170BHP (2017-) | 2017- | Brake Caliper: ATE | Front | Disc Diameter [mm]: 314 | |
| AUDI | A5 B9 | 2.0 Turbo 190BHP (2016-) | 2016- | Brake Caliper: ATE | Front | Disc Diameter [mm]: 314 | |
| AUDI | A5 B9 | 2.0 Turbo 252BHP (2016-) | 2016- | Brake Caliper: ATE | Front | Disc Diameter [mm]: 314 | |
| AUDI | A5 B9 | 3.0 TD 218BHP (2016-) | 2016- | Brake Caliper: ATE | Front | Disc Diameter [mm]: 314 | |
| AUDI | A5 Cabriolet B8 | 1.8 Turbo 158BHP (2009-2017) | 2009-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 Cabriolet B8 | 1.8 Turbo 170BHP (2011-2016) | 2011-2016 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 Cabriolet B8 | 2.0 TD 141BHP (2010-2017) | 2010-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 Cabriolet B8 | 2.0 TD 168BHP (2009-2011) | 2009-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 Cabriolet B8 | 2.0 Turbo 177BHP (2009-2011) | 2009-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 Cabriolet B8 | 2.0 Turbo 208BHP (2009-2017) | 2009-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 Cabriolet B8 | 2.7 TD 188BHP (2009-2011) | 2009-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 Cabriolet quattro B8 | 2.0 TD 177BHP (2011-2017) | 2011-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 Cabriolet quattro B8 | 2.0 Turbo 208BHP (2009-2017) | 2009-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 quattro B8 | 2.0 TD 168BHP (2008-2011) | 2008-2011 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 quattro B8 | 2.0 TD 174BHP (2011-2017) | 2011-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 quattro B8 | 2.0 Turbo 208BHP (2008-2017) | 2008-2017 | Brake Caliper: ATE | Front | Brake Pads: DB2184 | Disc Diameter [mm]: 314 |
| AUDI | A5 quattro B9 | 2.0 TD 150BHP (2016-) | 2016- | Brake Caliper: ATE | Front | Disc Diameter [mm]: 314 | |
