DBA
DBA5010BLKS
DBA5010BLKS
Prezzo di listino
€648,91 EUR
Prezzo di listino
Prezzo scontato
€648,91 EUR
Quantità
Impossibile caricare la disponibilità di ritiro
| Feature Description | Advantage | Benefit |
 "T3 Slot 48 precision CNC machined slots"
|
Tri-Symmetrical curve slots dampens the vibration harmonics or noise | A quieter, responsive and smoother brake pedal feel |
| Increased number of out-gassing exit points for brake pad friction gasses to escape through | Increases the consistency and effectiveness of every brake stop | |
| Universal slot design | Eliminates the need for left and right discs | |
 "KANGAROO_PAW") Kangaroo Paw – 144 diamond and tear drop pillar ventilation system
|
Increased surface area resulting in greater heat dissipation | Minimises brake fade and increases braking effectiveness |
| Increased surface area resulting in greater heat dissipation | Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs | |
 XG150 High Carbon Alloyed Iron
|
An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermal Stability Profiling
|
Special formulation designed to respond to DBA’s TSP process | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermographic Temperature Monitoring
|
Heat paint markings change colour at specific temperature thresholds | Offers the driver a clear indication of peak braking temperatures |
| When temperature thresholds are exceeded paint markings will permanently change colours | Allows the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims | |
 Paint protection on non-friction areas
|
Reduces corrosion | Stops any unsightly rust formation |
| Enhances appearance | Adds value to the product |
| Diameter [mm] | 295 |
| Disc Vent | Kangaroo Paw |
| Number of Holes | 5 |
| Inner Diameter [mm] | 58 |
| Minimum Thickness [mm] | 23 |
| Thickness [mm] | 25 |
| Height [mm] | 57.5 |
| Pitch Circle [mm] | 100 |
| Stage | Stage 5 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| ECE R90 number | E11*90R02/06*60536*00 |
| Compatibility | |||||||
|---|---|---|---|---|---|---|---|
| SUBARU | BRZ | 2.0 200BHP (2012-2022) | 2012-2022 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Forester | 2.0 150BHP (2013-2018) | 2013-2018 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Forester | 2.0 TD (2008-2013) | 2008-2013 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Forester | 2.0 TD 147BHP (2013-2018) | 2013-2018 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Forester | 2.5 (2003-2004) | 2003-2004 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Forester | 2.5 (2004-2008) | 2004-2008 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Forester | 2.5 Turbo (2004-2008) | 2004-2008 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Forester SG5 | 2.0 Turbo (2002-2003) | 2002-2003 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Forester SG5 | 2.0 Turbo (2003-2008) | 2003-2008 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Impreza | 2.0 TD (2009-2011) | 2009-2011 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Impreza | 2.0 TD (2011-2012) | 2011-2012 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Impreza | 2.0 Turbo Import (1998-2002) | 1998-2002 | Brake Caliper: Sumitomo | Front | Brake Pads: DB1170 | Disc Diameter [mm]: 294 |
| SUBARU | Impreza | 2.0 Turbo UK (1998-2002) | 1998-2002 | Brake Caliper: Sumitomo | Front | Brake Pads: DB1170 | Disc Diameter [mm]: 294 |
| SUBARU | Impreza | 2.0 Turbo WRX Import 190mm handbrake shoes (2001-2005) | 2001-2005 | Brake Caliper: Sumitomo | Front | Brake Pads: DB1170 | Disc Diameter [mm]: 294 |
| SUBARU | Impreza | 2.0 Turbo WRX UK 170mm handbrake shoes (2001-2005) | 2001-2005 | Brake Caliper: Sumitomo | Front | Brake Pads: DB1170 | Disc Diameter [mm]: 294 |
| SUBARU | Impreza | 2.5 Turbo WRX (2005-2007) | 2005-2007 | Brake Caliper: Sumitomo | Front | Brake Pads: DB1170 | Disc Diameter [mm]: 294 |
| SUBARU | Impreza | 2.5 Turbo WRX (2007-2008) | 2007-2008 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Impreza | 2.5 Turbo WRX-S (2008-2012) | 2008-2012 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Impreza GB270 | 2.5 Turbo (2007-2008) | 2007-2008 | Brake Caliper: Sumitomo | Front | Brake Pads: DB1170 | Disc Diameter [mm]: 294 |
| SUBARU | Legacy | 2.5 156BHP (1999-2003) | 1999-2003 | Front | Brake Pads: DB1342 | Disc Diameter [mm]: 294 | |
| SUBARU | Legacy | 2.5 165BHP (2003-2009) | 2003-2009 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Legacy | 2.5 167BHP (2009-2014) | 2009-2014 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Legacy | 2.5 173BHP (2007-2009) | 2007-2009 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Legacy | 3.0 209BHP (2000-2003) | 2000-2003 | Front | Brake Pads: DB1342 | Disc Diameter [mm]: 294 | |
| SUBARU | Legacy BE5 | 2.0 Twin Turbo 280BHP (1999-2003) | 1999-2003 | Front | Brake Pads: DB1342 | Disc Diameter [mm]: 294 | |
| SUBARU | Legacy BG5 | 2.0 Twin Turbo (1996-1999) | 1996-1999 | Front | Brake Pads: DB1342 | Disc Diameter [mm]: 294 | |
| SUBARU | Legacy BH5 | 2.0 Twin Turbo GT-B 260BHP (1999-2003) | 1999-2003 | Front | Brake Pads: DB1342 | Disc Diameter [mm]: 294 | |
| SUBARU | Legacy BH5 | 2.0 Twin Turbo GT-B 280BHP (1999-2003) | 1999-2003 | Front | Brake Pads: DB1342 | Disc Diameter [mm]: 294 | |
| SUBARU | Legacy BLD | 2.0 TD 150BHP (2008-2010) | 2008-2010 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Legacy BPD | 2.0 TD 150BHP (2008-2010) | 2008-2010 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Legacy BRD | 2.0 TD 150BHP (2009-2014) | 2009-2014 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Legacy Outback | 2.5 156BHP (1999-2004) | 1999-2004 | Front | Brake Pads: DB1342 | Disc Diameter [mm]: 294 | |
| SUBARU | Legacy Outback | 3.0 209BHP (2000-2004) | 2000-2004 | Front | Brake Pads: DB1342 | Disc Diameter [mm]: 294 | |
| SUBARU | Outback | 2.0 150BHP (2009-2014) | 2009-2014 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Outback | 2.0 TD 150BHP (2008-2010) | 2008-2010 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Outback | 2.0 TD 150BHP (2009-2014) | 2009-2014 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Outback | 2.5 163BHP (2003-2005) | 2003-2005 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Outback | 2.5 165BHP (2009-2014) | 2009-2014 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Outback | 2.5 173BHP (2006-2009) | 2006-2009 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | Outback | 3.0 245BHP (2003-2010) | 2003-2010 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | XV | 1.6 (2012-2017) | 2012-2017 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | XV | 2.0 (2012-2017) | 2012-2017 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| SUBARU | XV | 2.0 TD (2012-2017) | 2012-2017 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
| TOYOTA | GT86 | 2.0 200BHP (2012-2022) | 2012-2022 | Brake Caliper: Tokico | Front | Brake Pads: DB1491 | Disc Diameter [mm]: 294 |
