DBA52914.1L

5000 series - Plain - Rotor Only Left Hand

Diameter [mm]	375
Thickness [mm]	36
Disc Vent	72 Curved Vanes
Annulus [mm] (Maximum useable pad width)	59
Pitch Circle Diameter (P.C.D.)	247,65
Inside Diameter [mm]	257
Diameter & Number of Bolt Holes [mm]	6.4 (x12)
Air Gap [mm]	17
Offset [mm]	0
Flange Inside Diameter [mm]	231
Flange Thickness [mm]	6,6
Hole Type	Round Hole
Stage	Stage 5
Tech Bulletins	Bedding in Brakes
Tech Bulletins	How to clean a Disc Rotor before fitting
Tech Bulletins	Motorsport - Important Info
Replacement Nuts	Not Included
