DBA
DBA826S
DBA826S
Prezzo di listino
€187,25 EUR
Prezzo di listino
Prezzo scontato
€187,25 EUR
Quantità
Impossibile caricare la disponibilità di ritiro
| Feature Description | Advantage | Benefit |
 "T3 Slot 48 precision CNC machined slots"
|
Tri-Symmetrical curve slots dampens the vibration harmonics or noise | A quieter, responsive and smoother brake pedal feel |
| Increased number of out-gassing exit points for brake pad friction gasses to escape through | Increases the consistency and effectiveness of every brake stop | |
| Universal slot design | Eliminates the need for left and right discs | |
 "KANGAROO_PAW") Kangaroo Paw – 144 diamond and tear drop pillar ventilation system
|
Increased surface area resulting in greater heat dissipation | Minimises brake fade and increases braking effectiveness |
| Increased surface area resulting in greater heat dissipation | Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs | |
 XG150 High Carbon Alloyed Iron
|
An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermal Stability Profiling
|
Special formulation designed to respond to DBA’s TSP process | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermographic Temperature Monitoring
|
Heat paint markings change colour at specific temperature thresholds | Offers the driver a clear indication of peak braking temperatures |
| When temperature thresholds are exceeded paint markings will permanently change colours | Allows the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims | |
 Paint protection on non-friction areas
|
Reduces corrosion | Stops any unsightly rust formation |
| Enhances appearance | Adds value to the product |
| Diameter [mm] | 286 |
| Disc Vent | Solid |
| Number of Holes | 5 |
| Inner Diameter [mm] | 65.5 |
| Minimum Thickness [mm] | 8 |
| Thickness [mm] | 10 |
| Height [mm] | 69 |
| Stage | Stage 2 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| Compatibility | ||||||
|---|---|---|---|---|---|---|
| OPEL | Calibra | 2.0 Turbo (1995-1997) | 1995-1997 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| OPEL | Calibra | 2.5 (1995-1996) | 1995-1996 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| OPEL | Vectra | 1.6 (1999-2002) | 1999-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| OPEL | Vectra | 1.8 (1999-2002) | 1999-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| OPEL | Vectra | 2.0 (1995-2002) | 1995-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| OPEL | Vectra | 2.0 TD (1999-2002) | 1999-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| OPEL | Vectra | 2.2 (2000-2002) | 2000-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| OPEL | Vectra | 2.2 TD (2000-2002) | 2000-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| OPEL | Vectra | 2.5 (1995-2000) | 1995-2000 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| OPEL | Vectra | 2.5 GSi (1998-2000) | 1998-2000 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| OPEL | Vectra | 2.6 (2000-2002) | 2000-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| OPEL | Vectra | 2.6 GSi (2000-2002) | 2000-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| OPEL | Vectra i500 | 2.5 (1998-2000) | 1998-2000 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 900 | 2.0 (1996-1998) | 1996-1998 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 900 | 2.0 Turbo (1996-1998) | 1996-1998 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 900 | 2.3 (1996-1998) | 1996-1998 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 900 | 2.5 (1996-1998) | 1996-1998 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 9-3 | 2.0 (1998-2002) | 1998-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 9-3 | 2.0 Turbo (1998-2002) | 1998-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 9-3 | 2.0 Turbo Aero 205BHP (2000-2002) | 2000-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 9-3 | 2.2 TD (1998-2002) | 1998-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 9-3 | 2.3 (1998-2002) | 1998-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 9-3 | 2.3 Turbo (1999-2002) | 1999-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 9-3 | 2.3 Turbo Viggen 230BHP (1999-2002) | 1999-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 9-5 | 2.0 Turbo (1997-1999) | 1997-1999 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 9-5 | 2.3 Turbo 170BHP (1997-1999) | 1997-1999 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| SAAB | 9-5 | 3.0 Turbo 200BHP (1997-1999) | 1997-1999 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Calibra | 2.0 Turbo (1995-1998) | 1995-1998 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Calibra | 2.5 (1995-1998) | 1995-1998 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Vectra | 1.6 (1999-2002) | 1999-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Vectra | 1.8 (1999-2002) | 1999-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Vectra | 2.0 (1995-2000) | 1995-2000 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Vectra | 2.0 Super Touring (1996-1997) | 1996-1997 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Vectra | 2.0 TD (1999-2002) | 1999-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Vectra | 2.2 (2000-2002) | 2000-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Vectra | 2.2 TD (2000-2002) | 2000-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Vectra | 2.5 (1995-2000) | 1995-2000 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Vectra | 2.5 (1998-2000) | 1998-2000 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Vectra | 2.6 (2000-2002) | 2000-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
| VAUXHALL | Vectra | 2.6 GSi (2000-2002) | 2000-2002 | Brake Caliper: ATE | Rear | Disc Diameter [mm]: 286 |
