KAR20001-1B

Recommended for: Motorsport Applications

These kits are available with sprung ceramic friction discs and are designed for motorsport applications where higher heat and torque capacity is required. These can also be used in some road applications.

• Torque capacity 310Nm
• Clamp load 535kg Increased over standard
• Sprung Ceramic Friction Disc
• Heavy Duty Pressure Plate
• Kit contains everything you need for a successful installation + accessories

The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.

At Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.

Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

Clutch Disc Diameter (mm)	200
Clutch Disc Spline Count	24
Clutch Disc Spline Diameter (mm)	20.5
Torque (Nm)	310
Flywheel Step	-24.0mm/.945""
Design	Single Plate
Stage	Stage 2
Tech Bulletins
Clamp Load	535Kg
Recommended for	Track - Stage 2
Ring Gear Tooth count
Additional infotmation

Compatibility
Alfa Romeo	145	1.4 i.e.	1994.07-1996.12	AR 33501 1351 Petrol 66 kW 90 BHP (1994.07 - 1996.12)
Alfa Romeo	146	1.4 i.e.	1994.12-1996.12	AR 33501 1351 Petrol 66 kW 90 BHP (1994.12 - 1996.12)
Alfa Romeo	146	1.4 i.e. 16V T.S.	1996.11-2001.01	AR 33503, AR 38501 1370 Petrol 76 kW 103 BHP (1996.11 - 2001.01)
Alfa Romeo	145	1.4 i.e. 16V T.S.	1996.12-2001.01	AR 33503, AR 38501 1370 Petrol 76 kW 103 BHP (1996.12 - 2001.01)
Alfa Romeo	145	1.6 i.e.	1994.10-1996.12	AR 33201 1596 Petrol 76 kW 103 BHP (1994.10 - 1996.12)
Alfa Romeo	146	1.6 i.e.	1994.12-1996.12	AR 33201 1596 Petrol 76 kW 103 BHP (1994.12 - 1996.12)
