The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts.
  Ø184mm Light Diaphragm (2.6mm) Ø184mm Heavy Diaphragm (2.8mm)
Clamping Force 950kg 1080kg
Torque Rating 1600Nm 1820Nm
Bearing Contact Diameter 44-52mm 44-52mm
Bearing Load (@ 48mm) 210kg 260kg
Release Travel Required 5mm 5mm
Assembly Mass (without flywheel) 4.75kg 4.75kg
Disc Set Static Mass 1.2kg
Friction Thickness New 2.6mm (0.103") 2.6mm (0.103")
Friction Thickness Worn 2.36mm (0.093") 2.36mm (0.093")

Product Features:

  • Push type billet alloy cover
  • 4140 Chromoly pressure plate
  • Hardened steel wear posts
  • High and low ratio pressure plate options
  • Low inertia
  • Serviceable components
  • SFI certified design
Clutch Disc Diameter (mm) 184
Clutch Disc Spline Count 26
Clutch Disc Spline Diameter (mm) 28.6
Torque (Nm) 1830
Flywheel Step +2.5mm
Design Triple Plate
Stage Multiplate - track use only
Tech Bulletins
Clamp Load 900Kg
Recommended for Motorsport
Ring Gear Tooth count
Additional infotmation
Compatibility
Vauxhall VXR8 Maloo 6.2 2008.04-2011.08 LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2011.08)
Holden H Series VE | 6.0 Flex 2010.09-2013.04 L77(364CUV8) 5967 Petrol 260 kW 354 BHP (2010.09 - 2013.04)
Holden H Series VE | 6.0i V8 2006.07-2013.05 L76, L77(364CUV8) 5967 Petrol 260 kW 354 BHP (2006.07 - 2013.05)
Holden H Series VE | 6.0i V8 2006.07-2013.05 L77(364CUV8), L98(364CUV8) 5967 Petrol 270 kW 367 BHP (2006.07 - 2013.05)
Holden H Series VE | 6.0i V8 2006.08-2013.05 L77(364CUV8), L98(364CUV8) 5967 Petrol 270 kW 367 BHP (2006.08 - 2013.05)
HSV Senator VE | 6.0i V8 2006.08-2013.04 LS2(364CUV8) 5965 Petrol 297 kW 404 BHP (2006.08 - 2013.04)
HSV GTS VE | 6.0i V8 2006.08-2008.03 LS2(364CUV8) 5965 Petrol 307 kW 418 BHP (2006.08 - 2008.03)
HSV Senator VE | 6.0i V8 2006.08-2008.03 LS2(364CUV8) 5965 Petrol 307 kW 418 BHP (2006.08 - 2008.03)
HSV Clubsport VE | 6.0i V8 2006.08-2008.06 LS2(364CUV8) 5965 Petrol 307 kW 418 BHP (2006.08 - 2008.06)
HSV Maloo VE | 6.0i V8 2007.10-2008.03 LS2(364CUV8) 5965 Petrol 307 kW 418 BHP (2007.10 - 2008.03)
HSV GTS VE | 6.2i V8 2008.04-2010.10 LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2010.10)
HSV Clubsport VE | 6.2i V8 2008.04-2013.05 LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2013.05)
HSV Maloo VE | 6.2i V8 2008.04-2013.05 LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2013.05)
HSV Senator VE | 6.2i V8 2008.04-2013.05 LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2013.05)
HSV GTS VE | 6.2i V8 2010.10-2013.05 LS3(376CUV8) 6162 Petrol 325 kW 442 BHP (2010.10 - 2013.05)
HSV W427 VE | 7.0i V8 2008.07-2013.05 LS7 7009 Petrol 375 kW 510 BHP (2008.07 - 2013.05)
