KGM26003-1B

Recommended for: Motorsport Applications

These kits are available with sprung ceramic friction discs and are designed for motorsport applications where higher heat and torque capacity is required. These can also be used in some road applications.

• Torque capacity 690Nm
• Clamp load 1050kg 20% Increased over standard
• Sprung Ceramic Friction Disc
• Heavy Duty Pressure Plate
• Kit contains everything you need for a successful installation + accessories

The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.

At Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.

Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

Clutch Disc Diameter (mm)	255
Clutch Disc Spline Count	10
Clutch Disc Spline Diameter (mm)	28.6
Torque (Nm)	690
Flywheel Step	0
Design	Single Plate
Stage	Stage 2
Tech Bulletins
Clamp Load	1050Kg (20% inc.)
Recommended for	Track - Stage 2
Ring Gear Tooth count
Additional infotmation

Compatibility
Holden	H Series	5.0 i V8	1994.03-1995.04	50LB9 4987 Petrol 165 kW 224 BHP (1994.03 - 1995.04)
Holden	Commodore	VG | 5.0 V8	1988.01-1991.09	VU 4987 Petrol 165 kW 224 BHP (1988.01 - 1991.09)
HSV	Maloo	VG | 5.0i V8	1990.10-1992.02	VU 4987 Petrol 180 kW 245 BHP (1990.10 - 1992.02)
HSV	Clubsport	VN | 5.0i V8	1989.03-1991.09	4987 Petrol 180 kW 245 BHP (1989.03 - 1991.09)
Holden	H Series	VN | 5.0i V8	1988.10-1991.10	GMH 308 (Red) 4987 Petrol 165 kW 224 BHP (1988.10 - 1991.10)
Holden	H Series	VN | 5.0i V8	1988.01-1991.03	GMH 308 4987 Petrol 165 kW 224 BHP (1988.01 - 1991.03)
Holden	H Series	VN | 5.0i V8	1989.03-1991.10	GMH 308 4987 Petrol 165 kW 224 BHP (1989.03 - 1991.10)
HSV	Commodore	VN | 5.0i V8	1989.03-1990.12	GMH308 4987 Petrol 180 kW 245 BHP (1989.03 - 1990.12)
HSV	Commodore	VN | 5.0i V8	1989.03-1991.07	GMH308 4987 Petrol 200 kW 272 BHP (1989.03 - 1991.07)
Holden	H Series	VP | 5.0i V8	1991.09-1993.07	GMH 308 4987 Petrol 165 kW 224 BHP (1991.09 - 1993.07)
HSV	Clubsport	VP | 5.0i V8	1991.10-1993.06	VU 4987 Petrol 180 kW 245 BHP (1991.10 - 1993.06)
HSV	Maloo	VP | 5.0i V8	1992.03-1993.06	VU 4987 Petrol 180 kW 245 BHP (1992.03 - 1993.06)
HSV	Senator	VP | 5.0i V8	1992.03-1993.08	VU 4987 Petrol 180 kW 245 BHP (1992.03 - 1993.08)
HSV	Senator	VP | 5.0i V8	1992.05-1993.08	VU 4987 Petrol 200 kW 272 BHP (1992.05 - 1993.08)
Holden	H Series	VR | 5.0i V8	1993.10-1995.04	50LB9 4987 Petrol 165 kW 224 BHP (1993.10 - 1995.04)
Holden	H Series	VR | 5.0i V8	1994.03-1995.04	50LB9 4987 Petrol 165 kW 224 BHP (1994.03 - 1995.04)
Holden	H Series	VR | 5.0i V8	1993.10-1995.04	GMH 308 4987 Petrol 165 kW 224 BHP (1993.10 - 1995.04)
