KTY23005-1B
KTY23005-1B
Prezzo di listino
€493,37 EUR
Prezzo di listino
Prezzo scontato
€493,37 EUR
Quantità
Impossibile caricare la disponibilità di ritiro
Xtreme Outback - Heavy duty sprung ceramic kit /-1B
Recommended for: Motorsport ApplicationsXtreme Outback Ceramic upgrades have been designed to offer the ultimate in heat capacity for single plate upgrades and are designed specifically for motorsport applications such as endurance rally events and time trials. Available in Sprung Ceramic and Cushioned Ceramic, there are a wide variety of options to choose from depending on the vehicle use.Specifications:
- Torque capacity 430Nm
- Clamp load 700Kg 30% Increased over standard
- Ceramic Friction Disc
- Heavy Duty Pressure Plate
- Kit contains everything you need for a successful installation + accessories
Xtreme Outback
Designed and Engineered to handle the toughest conditions on the planet, Xtreme Outback Clutch Kits are the ultimate 4x4 heavy duty upgrade for the street and offroad.Each Xtreme Outback clutch kit is designed and developed to offer the ultimate balance between performance, durability and drivability. As used by motorsport teams and armoured car manufacturers across the globe, Xtreme Outback clutch kits can be trusted to get you there... and back again.
What's in the Box?
Xtreme Outback upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.
| Torque (Nm) | 430 |
| Clamp Load | 700KG (30% inc.) |
| Flywheel Step | +0.5mm |
| Clutch Disc Diameter (mm) | 225 |
| Clutch Disc Spline Count | 21 |
| Clutch Disc Spline Diameter (mm) | 29,8 |
| Recommended for | High Speed 4x4 Trial or Desert Race - Stage 2 |
| Design | Single Plate |
| Diameter [mm] | 225 |
| Stage | Stage 2 |
| Compatibility | |||||
|---|---|---|---|---|---|
| Toyota | 4 Runner | Gen. I | 2.8 D (LN61) | 1988.05-1989.10 | 3L 2779 Diesel 60 kW 82 BHP (1988.05 - 1989.10) | Suits vehicles manufactured from 09/1988. |
| Toyota | 4 Runner | Gen. II | 2.4 (RN130) | 1989.10-1996.03 | 22R 2367 Petrol 75 kW 102 BHP (1989.10 - 1996.03) | Suits vehicles manufactured from 07/1992. |
| Toyota | 4 Runner | Gen. II | 2.4 D (LN130) | 1989.08-1995.11 | 2L-T 2446 Diesel 66 kW 90 BHP (1989.08 - 1995.11) | Suits vehicles manufactured from 08/1992. |
| Toyota | Chaser | 1.8 (SX90) | 1992.10-1996.09 | 4S-FE 1838 Petrol 88 kW 120 BHP (1992.10 - 1996.09) | |
| Toyota | Dyna 100 | 1.8 (YY100_) | 1995.05-2001.07 | 2Y 1812 Petrol 59 kW 80 BHP (1995.05 - 2001.07) | |
| Toyota | Dyna 100 | 1.8 (YY100_) | 1995.05-2001.07 | 2Y 1812 Petrol 61 kW 83 BHP (1995.05 - 2001.07) | |
| Toyota | Dyna | 2.4 D (LH80_) | 1987.08-1995.04 | 2L 2446 Diesel 55 kW 75 BHP (1987.08 - 1995.04) | |
| Toyota | Dyna | 2.4 D (LH80_. LY50_. LY60_) | 1985.08-1995.05 | 2L 2446 Diesel 61 kW 83 BHP (1985.08 - 1995.05) | Suits vehicles manufactured from 08/1988. |
| Toyota | Hiace | Gen. III | 2.2 D (LH50. LH60) | 1982.12-1989.11 | L 2188 Diesel 49 kW 67 BHP (1982.12 - 1989.11) | Suits vehicles manufactured from 07/1988. |
| Toyota | Hiace | Gen. III | 2.4 D (LH61. LH51) | 1982.12-1989.11 | 2L 2446 Diesel 55 kW 75 BHP (1982.12 - 1989.11) | Suits vehicles manufactured from 01/1989. |
| Toyota | Hiace | Gen. IV | 2.4 D (LH100, LH110, LH104, LH114) | 1989.08-2004.12 | 2L 2446 Diesel 57 kW 78 BHP (1989.08 - 2004.12) | Suits vehicles manufactured until 08/1991. |
| Toyota | Hiace | Gen. IV | 2.4 D 4WD (LH51_. LH61_. LH66_. LH71_) | 1987.08-1995.08 | 2L 2446 Diesel 55 kW 75 BHP (1987.08 - 1995.08) | Suits vehicles manufactured until 08/1991. |
| Toyota | Hiace | Gen. IV | 2.4 D (LH112) | 1989.08-2004.08 | 2L 2446 Diesel 55 kW 75 BHP (1989.08 - 2004.08) | Suits vehicles manufactured until 08/1991. |
| Toyota | Hiace | Gen. IV | 2.4 D 4WD | 1989.09-1995.08 | 2L 2446 Diesel 57 kW 78 BHP (1989.09 - 1995.08) | Suits vehicles manufactured until 08/1991. |
| Toyota | Hilux | Gen. V | 2.5 (RN85) | 1988.10-1998.12 | 22R 2367 Petrol 75 kW 102 BHP (1988.10 - 1998.12) | |
| Toyota | Hilux | Gen. V | 2.4 4WD (RN105) | 1988.10-1997.12 | 22R 2367 Petrol 75 kW 102 BHP (1988.10 - 1997.12) | Suits vehicles manufactured from 07/1992. |
| Toyota | Hilux | Gen. V | 2.4 4WD (RN110, RN105, RN106) | 1988.10-1997.08 | 22R 2367 Petrol 75 kW 102 BHP (1988.10 - 1997.08) | Suits vehicles manufactured until 07/1992. |
| Toyota | Hilux | Gen. V | 2.4 (RN90, RN85) | 1988.10-1997.08 | 22R 2367 Petrol 75 kW 102 BHP (1988.10 - 1997.08) | |
| Toyota | Hilux | Gen. V | 2.4 D (LN85) | 1988.10-1997.07 | 2L 2446 Diesel 55 kW 75 BHP (1988.10 - 1997.07) | |
| Toyota | Hilux | Gen. V | 2.4 D (LN85, LN90) | 1991.10-1997.07 | 2L 2446 Diesel 59 kW 80 BHP (1991.10 - 1997.07) | |
| Toyota | Hilux | Gen. V | 2.4 D (LN85_, LN105, LN90) | 1988.09-1997.08 | 2L 2446 Diesel 61 kW 83 BHP (1988.09 - 1997.08) | Suits vehicles manufactured until 10/1991. |
| Toyota | Hilux | Gen. V | 2.4 D 4WD (LN105, LN110) | 1988.09-1997.08 | 2L 2446 Diesel 61 kW 83 BHP (1988.09 - 1997.08) | Suits vehicles manufactured until 10/1991. |
| Toyota | Hilux | Gen. V | 2.4 EFI 4WD (RN106_. RN110_) | 1989.01-1997.07 | 22RE 2367 Petrol 84 kW 114 BHP (1989.01 - 1997.07) | |
| Toyota | Land Cruiser 70 | 2.4 (RJ70_. RJ73_) | 1984.11-1993.05 | 22R 2367 Petrol 77 kW 105 BHP (1984.11 - 1993.05) | From 09/1988 |
| Toyota | Land Cruiser 70 | 2.4 (RJ70_. RJ73_. RJ70RV) | 1984.11-1993.05 | 22R 2367 Petrol 81 kW 110 BHP (1984.11 - 1993.05) | From 09/1988 |
| Toyota | Land Cruiser 70 | 2.4 (RJ70_V. RJ73_V) | 1988.12-1996.12 | 22RE 2367 Petrol 84 kW 114 BHP (1988.12 - 1996.12) | |
| Toyota | Land Cruiser 70 | 2.4 TD (LJ70_. LJ73_. LJ70RV) | 1985.10-1990.05 | 2L-T 2446 Diesel 63 kW 86 BHP (1985.10 - 1990.05) | Until 12/1989 |
